Configuration and performance

• The low center of gravity provides good stability.
• Excellent shock absorbers, quiet operation.
• The integrated pressure relief valve protects the stacker from overloads and thus increases reliability.
• Multifunction display.
• AC motor, without carbon brushes.
• Low voltage protection settings, extend battery life.
• The side battery is convenient for exchange and maintenance.
• The mast and frame are divisible and exchangeable.
• CAN bus technology reduces wiring complexity and increases reliability.
• The vertical drive wheel offers a small turning radius; The dust-proof motor is easy to maintain.
• Support feet on both sides for triplex mast.

Security

• Standard system configuration and emergency stop button.
• The truck can automatically decelerate during a rapid turn

 Technical characteristics:

• Load capacity: 2000 Kg
• Lifting height: 2500-5600mm
• Battery: 24V-300AH
• Maximum speed: 7.0-7.1Km/h
• Controller: CURTIS
